Dukung prosesor AMD Ryzen generasi 2 dan 3 dengan slot AM4. Kapasitas RAM hingga 64GB DDR4 dengan kecepatan 3466MHz, mendukung dual-channel untuk performa optimal. Dilengkapi PCIe x16 dan M.2 slot untuk penyimpanan cepat. Suport RGB lighting dan EZ Debug LED untuk pengaturan yang lebih mudah.
Spesifikasi
Harga
Rp1.811.000
12 produk(6 produk terjual)
Spesifikasi
Informasi dasar
Merek
MSI
Model
B450M PRO-VDH PLUS
Tanggal rilis
2019-02-01
Tipe soket
AM4
Prosesor yang didukung
AMD Ryzen 3, AMD Ryzen 5, AMD Ryzen 7, AMD Ryzen 9 (2nd & 3rd Gen), AMD Athlon
Cipset
AMD B450
Faktor bentuk
Micro-ATX
Memori
Kapasitas memori maksimal
64
Unit kapasitas memori maksimal
GB
Saluran memori
Dual-channel
Slot memori
4
Kecepatan memori
3466
Unit kecepatan memori
MHz
Tipe memori
DDR4-SDRAM
Dukungan xmp
Ya
Slot ekspansi
Slot m2
[{'quantity': 1, 'interface': 'PCIe 3.0 x4 atau SATA 6Gb/s', 'max_speed': '32 Gb/s'}]
Slot pcie
[{'type': 'PCIe 3.0 x16', 'quantity': 1, 'speed': '16 GT/s'}, {'type': 'PCIe 2.0 x1', 'quantity': 2, 'speed': '5 GT/s'}]
Penyimpanan
Port sata
4
Kecepatan sata
6Gb/s
Fitur
Fitur bios
BIOS standar
Fitur debug
EZ Debug LED
Header rgb
1
Dukungan rgb
Ya
Konektivitas
Jaringan
Ethernet
Gigabit Ethernet (Realtek 8111H)
Port usb
[{'type': 'USB 2.0', 'quantity': 8, 'speed': '480 Mbps'}, {'type': 'USB 3.1 Gen1', 'quantity': 6, 'speed': '5 Gbps'}]
Output video
Hdmi
1
D sub
1
Spesifikasi fisik
Panjang
244
Unit panjang
mm
Lebar
244
Unit lebar
mm
Pendingin
Header kipas
3
Heatsink
VRM heatsink
Audio
Saluran
7.1
Kodek
Realtek ALC892
Fitur
Studio-grade sound quality
Sistem daya
Konektor daya
[{'type': 'ATX 24-pin', 'quantity': 1}, {'type': 'EPS 8-pin', 'quantity': 1}]
