Motherboard MSI B760 Gaming Plus WiFi dengan desain ATX yang mendukung prosesor Intel Core generasi ke-14, ke-13, dan ke-12. Dilengkapi dengan soket LGA 1700 dan memori DDR5 hingga 192GB kapasitas maksimal. Fitur PCIe 4.0 x16 untuk kartu grafis berkinerja tinggi, serta dua slot M.2 PCIe 4.0 x4 yang mendukung kecepatan hingga 64 Gbps. Konektivitas lengkap dengan Wi-Fi 6E, Bluetooth 5.3, dan port USB 3.2 Gen2 Type-A & Type-C. Sistem daya 12+1+1 fase digital PWM untuk stabilitas maksimal. Audio Boost 7.1 channel dengan isolasi sinyal audio dan proteksi De-Pop. Desain pendingin yang efisien dengan heatsink ekstensif, M.2 Shield Frozr, dan VRM Heatsink. Dukungan RGB dan fitur BIOS Click BIOS 5 untuk pengaturan mudah.
Spesifikasi
Harga
Rp1.300.000
1483 produk(165 produk terjual)
Blibli
Rp1.675.000
70 produk
Lazada
Rp1.729.900
2 produk
Berita
Spesifikasi
Informasi dasar
Merek
MSI
Model
B760 Gaming Plus WiFi
Tipe soket
LGA 1700
Prosesor yang didukung
Intel Core 14th Gen, Intel Core 13th Gen, Intel Core 12th Gen, Intel Pentium Gold, Intel Celeron
Cipset
Intel B760
Faktor bentuk
ATX
Memori
Kapasitas memori maksimal
192
Unit kapasitas memori maksimal
GB
Saluran memori
Dual
Slot memori
4
Kecepatan memori
6800
Unit kecepatan memori
MHz
Tipe memori
DDR5
Dukungan xmp
Intel XMP 3.0
Slot ekspansi
Slot m2
[{'quantity': 2, 'interface': 'PCIe 4.0 x4', 'max_speed': '64 Gbps'}]
Slot pcie
[{'type': 'PCIe 4.0 x16', 'quantity': 2, 'speed': 'Gen4'}, {'type': 'PCIe 3.0 x1', 'quantity': 3, 'speed': 'Gen3'}]
Penyimpanan
Port sata
4
Kecepatan sata
6 Gbps
Fitur
Fitur bios
Click BIOS 5, XMP, Hardware Monitor, Memory Try It, M-Flash
Fitur debug
EZ Debug LED
Header rgb
2
Dukungan rgb
Ya
Konektivitas
Jaringan
Ethernet
2.5G LAN
Wifi
Wi-Fi 6E
Bluetooth
5.3
Port usb
[{'type': 'USB 3.2 Gen2 Type-A', 'quantity': 2, 'speed': '10 Gbps'}, {'type': 'USB 3.2 Gen2 Type-C', 'quantity': 1, 'speed': '10 Gbps'}, {'type': 'USB 2.0', 'quantity': 4, 'speed': '480 Mbps'}]
Output video
Hdmi
1
Displayport
1
Pendingin
Header kipas
7
Heatsink
Extended Heatsink, M.2 Shield Frozr, VRM Heatsink
Header pompa
1
Audio
Saluran
7.1
Kodek
Audio Boost
Fitur
Isolasi sinyal audio, Proteksi De-Pop, Jack audio definisi tinggi
Sistem daya
Konektor daya
[{'type': '8-pin', 'quantity': 1}, {'type': '4-pin', 'quantity': 1}]
Fase daya
12+1+1
Solusi vrm
Digital PWM
