Dukungan prosesor Intel Core 14th Gen hingga Celeron, dengan memori DDR5 hingga 128GB dan kecepatan 7800MHz. Dilengkapi PCIe 5.0 x16 dan 5 slot M.2 PCIe 5.0/4.0 untuk performa tinggi. Fitur Wi-Fi 7, Thunderbolt 4, dan audio 7.1 dengan ESS DAC memberikan pengalaman gaming yang optimal.
Spesifikasi
Harga
Blibli
Rp12.150.000
3 produk
Rp12.199.000
67 produk(12 produk terjual)
Spesifikasi
Informasi dasar
Merek
MSI
Model
MEG Z790 ACE
Tipe soket
LGA 1700
Prosesor yang didukung
Intel Core 14th Gen, Intel Core 13th Gen, Intel Core 12th Gen, Intel Pentium Gold, Intel Celeron
Cipset
Intel Z790
Faktor bentuk
E-ATX
Memori
Kapasitas memori maksimal
128
Unit kapasitas memori maksimal
GB
Saluran memori
Dual Channel
Slot memori
4
Kecepatan memori
7800
Unit kecepatan memori
MHz
Tipe memori
DDR5
Dukungan xmp
Intel XMP 3.0
Slot ekspansi
Slot m2
[{'quantity': 5, 'interface': 'PCIe 5.0/4.0', 'max_speed': '128 Gbps'}]
Slot pcie
[{'type': 'PCIe 5.0 x16', 'quantity': 1, 'speed': '128 Gbps'}, {'type': 'PCIe 5.0 x8', 'quantity': 1, 'speed': '64 Gbps'}, {'type': 'PCIe 4.0 x4', 'quantity': 1, 'speed': '16 Gbps'}]
Fitur
Fitur bios
Click BIOS 5, Dual BIOS, Search and Favorites in BIOS
Fitur debug
Debug LED, Clear CMOS Button, Flash BIOS Button
Dukungan rgb
Ya
Konektivitas
Jaringan
Ethernet
Dual 2.5G LAN
Wifi
Wi-Fi 7
Bluetooth
Bluetooth 5.4
Port usb
[{'type': 'USB 3.2 Gen 2x2 Type-C', 'quantity': 2, 'speed': '20 Gbps'}, {'type': 'Thunderbolt 4 (USB-C)', 'quantity': 2, 'speed': '40 Gbps'}]
Output video
Displayport
1
Pendingin
Heatsink
Direct Touch Cross Heat-pipe, Double-sided M.2 Shield Frozr, Aluminum Backplate
Header pompa
2
Audio
Saluran
7.1
Kodek
ALC4082
Fitur
Audio Boost 5 HD, ESS DAC, Dedicated Headphone Amplifier
Sistem daya
Konektor daya
[{'type': '8-pin', 'quantity': 2}]
Fase daya
24+1+2
Solusi vrm
105A Smart Power Stage
